12 volt battery

[GMB]

You need one of these.



[Heuer]

14 hours ago, Don C said:

I know some of you will argue that you shouldn’t have to do it but I fitted an upgraded battery on my mate’s LBX today.  You don’t have to do it, it’s up to you but you can see the capacity is well up.  It’s under the back seat, took me about 20 minutes and it cost just over £71 with a 5 year warranty.

Hi Don

I am thinking of doing this swap as it is more cost effective than buying a quality jumper pack. Any chance you can list the steps in accessing the Battery along with hints on how to do it without breaking any of the trim?

Thanks

David

[Herbie]

1 hour ago, iainmangle said:

"Once and for all" 🙂 . Sorry, I hadn't realised you were the resident expert and arbiter of what is and isn't OK.

Yep, that's me and I forgive you. But, now that you know....

1 hour ago, iainmangle said:

With respect, your argument defeats itself; you cannot say it isn't a Lexus problem and in the next breath that Lexus made a decision - one led to the other so it is exactly a Lexus problem.

OK, yes, I agree, but what I meant was that it isn't a 'fixable' fault. It's a design flaw that never should have got off the drawing board 10 or more years ago and you only need to look at the debacle over the CANbus thefts to know that they won't do anything retrospectively to the cars out there that already have this flaw. Even if they were willing, I'm not sure they could; some of the Battery boxes and Battery locations are just so small with no room for a bigger Battery anyway.

The only things you can do are to (a) keep the car on a trickle charger, or (b) use it more often, or (c) just sit in it for an hour per week with it in READY mode, as per Lexus' own instructions during Covid lockdown.



[Herbie]

4 hours ago, Don C said:

Sorry, I understood you to say that there’s no point discussing it further and I was up early so can come across curt.

No worries Don

[Don C]

4 hours ago, Heuer said:

Hi Don

I am thinking of doing this swap as it is more cost effective than buying a quality jumper pack. Any chance you can list the steps in accessing the battery along with hints on how to do it without breaking any of the trim?

Thanks

David

Yes, no problem.  Bear with me 👍

[Tel]

Lian,

Clearly you have a dodgy Battery that is causing you massive heart ache.

Some of the Peeps on here have adopted the Lexus hybrid protocol & many on Facebook.

Don & Herbie have explained the Hybrid Battery shortcomings but your experience is extreme & rare.

Trust you will sort it soon,

Tel

[Shufman]

On 10/31/2024 at 10:56 AM, Geotechnic said:

Having read the posts for the LBX and the Toyota equivalent I purchased a jump pack before I got the car, sits quite happily under the passenger seat (can't imagine that's going to get hotter than 75 degrees C) As yet have had no starting issues, using the car two to three times a week, less than 100 miles of travel. Given the problems others have reported I've been checking the 12v battery voltage with a multimeter at the battery, with the car open but off, the battery has been reading 12.4v to 12.6v. I'm assuming the very act of unlocking the car will cause some systems to switch on so not expecting it to show fully charged, 12.7v-12.8v. The lower 12.4v was after three days sitting on the drive unused. I am waiting on the arrival of a bluetooth battery monitor to fit directly to the battery(ebay £20) so I can monitor the battery when the car is locked. Wonder if anybody has checked the battery voltage on a non-starting car before jumping it to see how low it was?

I got caught out a couple of months ago when it died on the driveway, I’d had doors open and been loading the car with stuff for a while. I’ve had several hybrids (Yaris and 2019 Corolla) and never had any issues with doors, lights etc. the AA guy took the voltage and it was 3.3 V so really low … it started when he jumped it and Lexus changed the Battery a few days later. A mastertech friend said that they’ve modified the batteries now to hold more charge, the only thing I do now is when I clean the car I leave it in READY with everything off and it’s fine. It’s used most days though.

[Don C]

10 hours ago, iainmangle said:

Are you suggesting the "hybrid protocol" justifies a battery that needs 2 AA visits, five jump starts and two 24 hour charges in a month? According to the numbers floating around I should be able to leave my LBX undisturbed for a month and still expect it to start, but maybe mine didn't read the "hybrid protocol". My previous hybrids have not presented an issue so maybe they read the protocol. Very lazy to attribute responsibility for poor engineering and cost cutting by a supposedly innovative manufacturer to the people who fork out £40k for what is meant to be a high end vehicle..

I don’t think a month is unreasonable.  To be fair, I don’t think it’s poor engineering or cost cutting because the last thing they want is disgruntled customers and everything that goes with it.  Something appears miscalculated there’s no doubt.  What do you intend to do about it?

[Heuer]

Quick question on Battery replacement. Will fitting a larger capacity Yusaa HSB 202 45aH Battery invalidate the Lexus warranty as it is out of spec?

[NemesisUK]

6 minutes ago, Heuer said:

Quick question on battery replacement. Will fitting a larger capacity Yusaa HSB 202 45aH battery invalidate the Lexus warranty as it is out of spec?

Only if the fault can be attributed to the Battery in any way..

[kevinc23]

Mine not working, but changed the Battery and started ticking away....not my LBX but a Lexus watch my wife had bought me for a present. What is it with Lexus and batteries. Thinking of fitting a Battery monitor to it

[Heuer]

On 11/3/2024 at 12:30 PM, NemesisUK said:

Only if the fault can be attributed to the battery in any way..

Given the dealers seem to attribute the bad Battery problem as "user error" or "no fault found" I think they will look for any excuse to blame the owner for fitting a 'bigger' one regardless of the fault! Not sure I want to take the chance.

Having said that there are now replacement Lithium 12v batteries which are light and small. Should be able to get a 60aH in there.
